100mm~ 1000mm
DORI Distance
Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.Detect
Observe
Recognize
Identify
2731m(8960ft)
1092m(3583ft)
546m(1791ft)
273m(896ft)
PTZ
Pan/Tilt Range
Pan: 0° ~ 360° endless; Tilt: -90° ~ 45°
Manual Control Speed
Pan: 0.1° ~160° /s; Tilt: 0.1° ~60° /s
Preset Speed
Pan:160° /s; Tilt: 60° /s
Presets
300
PTZ Mode
5 Pattern, 8 Tour, Auto Pan ,Auto Scan
Speed Setup
Human-oriented focal Length/ speed adaptation
Power up Action
Auto restore to previous PTZ and lens status after
power failure
Idle Motion
Activate Preset/ Scan/ Tour/ Pattern if there is no
command in the specified period
Protocol
DH-SD, Pelco-P/D (Auto recognition)
Intelligence
Event Trigger
Motion detection, Video tampering , Scene changing, Network disconnection, IP address conflict, Illegal Access, Storage anomaly
Auto Tracking
Support
IVS
Tripwire, Intrusion, Abandoned/Missing
Advanced Intelligent Functions
Face Detection, Heat Map
Video
Compression
H.265+/H.265/H.264+/H.264
Streaming Capability
3 Streams
Resolution
1080P(1920×1080)/1.3M(1280x960)/720P(1280× 720)/D1(704×576/704×480)/CIF(352×288/352×240)
Frame Rate
Main stream: 1080P/1.3M/720P(1~50/60fps)
Sub stream1: D1/CIF(1 ~ 25/30fps)
Sub stream2: 1080P/1.3M/720P (1 ~ 25/30fps)
Bit Rate Control
CBR/VBR
Bit Rate
H.265/H.264: 448K ~ 8192Kbps
Day/Night
Auto(ICR) / Color / B/W
Backlight Compensation
BLC / HLC / WDR (120dB)
White Balance
Auto, ATW, Indoor, Outdoor, Manual
Gain Control
Auto / Manual
