1920 × 1080 (OSD black strip excluded)
Video Resolution
Main stream: 1080P (1920 × 1080) / 720P (1280 × 720)
Sub stream: 720P (1280 × 720) / D1 (704 × 576, 704 × 480) / CIF (352 × 288, 352 × 240)
Video Frame Rate
PAL: Main stream (1920 × 1080@25fps, 1280 × 720@25fps), sub stream: (1280 × 720@25fps, 704 × 576@25fps, 352 × 288@25fps)
NTSC: Main stream (1920 × 1080@30fps, 1280 × 720@30fps), sub stream (1280 × 720@30fps, 704 × 408@30fps, 352 × 240@30fps)
Bit Rate
H.264B: 32Kbps–32768Kbps
H.264M: 32Kbps–32768Kbps
H.264H: 32Kbps–32768Kbps
H.265: 32Kbps–32768Kbps
MJPEG: 512Kbps–65536Kbps
Video Encoding
H.264B/H.264M/H.264H/H.265/MJPEG
Image Encoding
JPEG
Noise Reduction
3DNR
White Balance
Full auto; auto color temperature range; customized color temperature
Electronic Shutter
1/50–1/10000, auto or manual
Wide Dynamic Range
96db
Edge Enhancement
Yes
Exposure Mode
Full auto; customized auto; customized
Iris
Auto iris (W:1.3–T:2.3)
Function
Trigger Mode
Video detection; I/O coil; video detection and I/O coil
Shutter
Single shutter
Storage
1 built-in TF card port. Kingston 16G, 32G and 64G; Dahua 16G, 32G and 64G; SanDisk 16G, 32G and 64G
Image Tampering Prevention
Yes. Video/picture can be checked through watermark and verification
Max Illumination Distance
30 m (98.43 ft)
Capture Range
8 m–30 m (26.25 ft–98.43 ft)
Detected Lane Width
6 m –7 m (19.69 ft–22.97 ft)
Min Ambient Illuminance
0.002 Lux. Illuminator is designed with the camera for illumination
Max Speed that the Camera Detects
60 km/h
Alarm Event
Alarm in the case of no storage card, not enough storage space, storage card error, network disconnection, IP conflict, and illegal access
Security Mode
Authorized username and password, MAC address binding, HTTPS encryption, IEEE 802.1x, and network access control
OSD Overlay
Supports overlay of time, address (position of channel), lane (number/direction), plate (number and color), vehicle (speed, color, type)
ANR (Automatic Network Replenishment)
Yes. Platform/FTP
Auto Register
Yes
Intelligence
Vehicle Detection
Vehicle capture rate ≥99%
Vehicle Recognition
Supports recognizing vehicle type, vehicle logo, vehicle color, license plate, and vehicle without plate. Vehicle recognition rate ≥95%
Video Metadata
Yes
Intelligent Track Frame
Intelligent frame display. Supports displaying vehicle plate and vehicle path
Ports
Lens
Lens in the camera module
Analog Output
1
Ethernet Port
1 100/1000M Ethernet port (RJ45)
RS-485 Port
2
RS-232 port
1
Alarm Input
3, optocoupler input (switch quantity)
Alarm Output
3 ports. 2-channel optocoupler output, 1-channel relay output, which can connect to devices such as barriers
Audio Input
1-channel RCA port
Audio Output
1-channel RCA port
General
Power Supply
12V DC, 24V AC, PoE+
Power Consumption
< 20W
Working Temperature
−30°C to +65°C (−22°F to +149 °F)
Working Humidity
10%–90% (no condensation)
Housing
